Table Saw

Primary tabs

The Table Saw is used primarily to rip wood.

Requirements for Use
Required Badges:

Table Saw

Watch Video
Pass Quiz
Quiz:
In person checkout required
Facilitator Checkout
Estimated Minutes for Checkout:
15 Minutes

Check Out With Facilitator

Community Facilitators are volunteers who to advise MakeHaven members on projects and show members how to use the tools.

Facilitator hours will be BY APPOINTMENT during their listed hours. To make an appointment, contact the facilitator directly via Slack. To prevent unnecessary space access during the pandemic, facilitators will not be in the space unless they have an appointment. Note that some facilitators are available only for online virtual appointments at this time. Any questions please email info@makehaven.org.

Community Facilitators are volunteers who to advise MakeHaven members on projects and show members how to use the tools.



When Member Photo Name / Activity Area
Wednesday Aug 17, 6:00pm to 9:00pm

Jared Crouch

Metal Shop & Woodworking


Wednesday Aug 17, 6:00pm to 9:00pm

Walker Fuchs

Woodworking


Mask required

Monday Aug 22, 6:00pm to 9:00pm

Mike Lockett

Woodworking


Show other badgers not on schedule:

Additional Badgers

Unscheduled Badger

Additional people who can badge on this tool, by special appointment only.

Member Photo Availability

Jen Fremd

Woodworking


Only by special arrangement
Special Requirements:

Buddy System

Tools identified as requiring the buddy system can not be used alone by a member in the space. Another person who is willing and able to respond in an emergency must be identified, informed and consent that they are acting as a buddy.  This buddy must remain in the space and be able to observe if any issue arises. The designated buddy must be able to see and hear their partner in person (not just video). Metal shop buddy must be in the metal shop with opperator. The buddy must inform the member operating the tool if they intend to leave so that the tool operator can stop use of any tools requiring the buddy system.

Additional Badges:
Instructions for Use:
Run the saw in Normal Mode to cut non-conductive materials like wood, plastic, cardboard, foam, Corian, melamine and dry pressure-treated wood.

Conductive materials will trigger the SawStop. You will need to use bypass mode to Run the saw when cutting conductive materials like metal, very wet or very green wood,  Carbon-filled materials, mirrored acrylic, carbon fiber materials and wet pressure-treated wood.

What do I do if I activate the safety system's brake cartridge? What will it cost to reset the safety system? Does activation damage the saw?

If you activate the safety system’s brake, you will need to replace the blade and replace the brake cartridge. A standard brake cartridge costs $100 and a dado brake cartridge $120. SawStop saws are designed to absorb the force of activation and are not damaged by it.

Can I cut conductive materials?
Yes. You can operate the saw in Bypass Mode which deactivates the safety system’s braking feature, allowing you to cut aluminum and other known conductive materials. If you are unsure if material you need to cut is conductive, you can make test cuts using Bypass Mode to determine if it will activate the safety system’s brake.

What happens if the blade comes in contact with a nail or staple in the wood?
Generally, the safety system will not activate when a nail or staple is cut. Although conductive, these objects are not large enough to cause the safety system to activate unless they are grounded to the table or operator when they contact the blade.

Will cutting green or "wet" wood activate the SawStop system?
SawStop saws cut most wet wood without a problem. However, if the wood is very green or wet (for example, wet enough to spray a mist when cutting), or if the wood is both wet and pressure treated, then the wood may be sufficiently conductive to trigger the brake. Accordingly, the best practice is to dry wet or green wood before cutting by standing it inside and apart from other wood for about one day. You can also cut wet pressure treated wood and other conductive material by placing the saw in bypass mode to deactivate the safety system.

Read the Full Manual Online


Location:
Wood Shop
Item Area Interest:
Status:

Materials for Sale

Custom text
DIABLO 10 in. x 50-Teeth Combination Saw Blade Replacement blade for our saw stop $48.00 per 1 Add to cart
Sawstop Cartridge Brake, Dado Size Replacement Dado sawstop blade for when triggered $145.00 per 1 Brake Add to cart
Sawstop Cartridge Brake, Normal Size $137.00 per 1 Brake Add to cart
